Subaru forester with lift kit

LP Aventure lift kit — Subaru Forester 2019-2021

Improve the look and the ground clearance of your Subaru Forester 2019-2020 with the LP Aventure lift kit. The lift kit is designed by our team that has over 20 years of experience in off-road.

ADVANTAGES:

• FMVSS 126 compliant.
  When it comes down to innovation, Safety and quality, LP Aventure is always a leader in the industry. One more example of this is having our LP Aventure lift kit & packages compliant with the NHTSA and it’s FMVSS126 Federal Motor Vehicle safety standard.

Manufactured in stainless steel.
The top plate spacers are designed with 304 stainless steel and they are TIG welded. They are tough, durable and resistant to corrosion.

Offset design.
The offset design keeps the original camber specifications to facilitate the alignment of the car.

Multi links spacers.
These spacers lowers the rear subframe of the car to keep the original alignment specifications and optimizes the vehicle’s handling. In addition they help to maintain the original positioning of the rear wheels. Which is very useful to prevent rubbing when using larger diameter tires.

Lengthened brake lines spacers.
The lift kit includes elongated brake line spacers that allow easy installation which does not require to replace original brake lines.

• Complete hardware.
  All hardware required for installation is included.

• Aluminum-engineered sway bar spacers.
  Machined from high quality aluminum blocks, with a CNC machine, these supports are machined with the highest precision.


Warning: This product may contain a chemical known to the State of California to cause cancer, birth defects, or other reproductive harm.

Источник

LEVELING KITS

SST LIFT KITS

COMPLETE BIG LIFT KITS

REAR LIFT

SUPER DUTY LIFT KITS

SUBARU LIFT KITS

JEEP SUSPENSION

LOAD LEVELING KITS

SHOCKS

ACCESSORIES

TOOLS

Shop All Parts

CLEARANCE / OUTLET

2.0″ SST Lift Kit- Subaru Forester 2014-2018

2.0″ SST Lift Kit — 2014-2018 Subaru Forester

Allows for up to a 225/75-15 tire on a 15×7 wheel with +15 offset

2″ front lift / 1.5″ rear lift

Increases ground clearance

ReadyLIFT now offers a great lift solution for the 2014-2018 MY Subaru Forester. The Subaru Forester is extremely popular with adventure enthusiasts. Using the same lift technology developed for the Crosstrek, our engineers have designed a brand new lift solution that will raise the 2014-2018 Subaru Forester 2″ for a taller stance that increases ground clearance and allows for larger tires.

Using our time-tested lift engineering technology from our award-winning, best-selling truck and Jeep lift kits, our engineers developed the 69-9420 SST Lift Kit for 2014-2018 Forester vehicles to provide 2″ of front lift and 1.5″ of rear lift for trouble-free Subaru adventures. Both front and rear offset design spacers are fabricated from heavy-duty steel and protected with a durable powder coat finish. This lift combination creates an exceptional improved stance that, when combined with a P225 tire, results in a substantial increase of ground clearance at the rockers.

This kit is completely bolt-on and requires no modifications, installs in half the time of other kits, and retains the factory camber/caster for ideal alignment courtesy of our unique offset spacer design. This new Forester SST Lift Kit maintains the factory ride while accommodating up to a brawny 225/75-15 tire on a 15×7 wheel with +15 mm offset and requires no trimming.

• Allows for up to a 225/75-15 tire on a 15×7 wheel with +15 offset.Allows for up to a 235/75-15 tire on a 15×7 wheel with +15 offset with minor plastic trimming.
• If you are looking for a premium quality lift kit for your Outback, our 2″ lift kit is perfect for you without having to overpay for components you don’t need.
• Offset designed fabricated heavy-duty steel plate top-mount strut extensions maintain factory alignment geometry.
• Easy, bolt-on installation — no permanent modifications.
• Delivers increased ground clearance.
• Allows for increased tires sizes that are ideal for trail adventures.
• Made in USA.

NOTE: Some lifted Subaru models may exhibit low speed ‘rumble’ or ‘wobble’ between 17-22 MPH. This is the result soft and/or aging rubber in the factory transmission mount that may become noticeable with the new CV angles of the lifted vehicle. The issue can be addressed with an affordable aftermarket ‘anti-wobble’ transmission mount or mount insert.

225/75-15 15×7 +15 offset for no rub.

235/75-15-15×7 +15 offset requires minor plastic trimming in front.

When lifting a vehicle and installing aftermarket wheels and tires, a tire manufacturer’s construction and material quality can alter vehicle ride quality. When increasing a vehicle wheel and tire size, most larger aftermarket truck and SUV tires are 8-ply (or more) E tires compared to typical OEM 6-ply C tires. This more rigid sidewall construction increases the perception of suspension stiffness often described as ride harshness. The ride, handling, traction, noise, fuel economy, and wear differences between All-Season, All-Terrain, Mud-Terrain, or Trail-Terrain type tires can be significant. Please take into account tire and wheel choice will generally have a meaningful impact on the ride & handling experience.

Two (2) heavy-duty fabricated steel front lift spacers.

Two (2) heavy-duty fabricated steel rear lift spacers.

All necessary hardware and instructions.

Do it yourself!

Please read Instructions thoroughly and completely before beginning installation. Installation by a certified mechanic is recommended. ReadyLIFT Suspension Inc. is NOT responsible for any damage or failure resulting from improper installation.

Have a certified mechanic do it for you!

2.0″ SST Lift Kit — 2014-2018 Subaru Forester

Allows for up to a 225/75-15 tire on a 15×7 wheel with +15 offset

2″ front lift / 1.5″ rear lift

Increases ground clearance

ReadyLIFT now offers a great lift solution for the 2014-2018 MY Subaru Forester. The Subaru Forester is extremely popular with adventure enthusiasts. Using the same lift technology developed for the Crosstrek, our engineers have designed a brand new lift solution that will raise the 2014-2018 Subaru Forester 2″ for a taller stance that increases ground clearance and allows for larger tires.

Using our time-tested lift engineering technology from our award-winning, best-selling truck and Jeep lift kits, our engineers developed the 69-9420 SST Lift Kit for 2014-2018 Forester vehicles to provide 2″ of front lift and 1.5″ of rear lift for trouble-free Subaru adventures. Both front and rear offset design spacers are fabricated from heavy-duty steel and protected with a durable powder coat finish. This lift combination creates an exceptional improved stance that, when combined with a P225 tire, results in a substantial increase of ground clearance at the rockers.

This kit is completely bolt-on and requires no modifications, installs in half the time of other kits, and retains the factory camber/caster for ideal alignment courtesy of our unique offset spacer design. This new Forester SST Lift Kit maintains the factory ride while accommodating up to a brawny 225/75-15 tire on a 15×7 wheel with +15 mm offset and requires no trimming.

• Allows for up to a 225/75-15 tire on a 15×7 wheel with +15 offset.Allows for up to a 235/75-15 tire on a 15×7 wheel with +15 offset with minor plastic trimming.
• If you are looking for a premium quality lift kit for your Outback, our 2″ lift kit is perfect for you without having to overpay for components you don’t need.
• Offset designed fabricated heavy-duty steel plate top-mount strut extensions maintain factory alignment geometry.
• Easy, bolt-on installation — no permanent modifications.
• Delivers increased ground clearance.
• Allows for increased tires sizes that are ideal for trail adventures.
• Made in USA.

NOTE: Some lifted Subaru models may exhibit low speed ‘rumble’ or ‘wobble’ between 17-22 MPH. This is the result soft and/or aging rubber in the factory transmission mount that may become noticeable with the new CV angles of the lifted vehicle. The issue can be addressed with an affordable aftermarket ‘anti-wobble’ transmission mount or mount insert.

225/75-15 15×7 +15 offset for no rub.

235/75-15-15×7 +15 offset requires minor plastic trimming in front.

When lifting a vehicle and installing aftermarket wheels and tires, a tire manufacturer’s construction and material quality can alter vehicle ride quality. When increasing a vehicle wheel and tire size, most larger aftermarket truck and SUV tires are 8-ply (or more) E tires compared to typical OEM 6-ply C tires. This more rigid sidewall construction increases the perception of suspension stiffness often described as ride harshness. The ride, handling, traction, noise, fuel economy, and wear differences between All-Season, All-Terrain, Mud-Terrain, or Trail-Terrain type tires can be significant. Please take into account tire and wheel choice will generally have a meaningful impact on the ride & handling experience.

Two (2) heavy-duty fabricated steel front lift spacers.

Two (2) heavy-duty fabricated steel rear lift spacers.

All necessary hardware and instructions.

Do it yourself!

Please read Instructions thoroughly and completely before beginning installation. Installation by a certified mechanic is recommended. ReadyLIFT Suspension Inc. is NOT responsible for any damage or failure resulting from improper installation.

Источник

2″ All Terrain Suspension Kit Suited For 2019+ Subaru Forester SK

Ironman 4×4

FREE SHIPPING ON ORDERS OVER $99

WARRANTY
UP TO 3 YEARS

30-DAY GUARANTEE RETURNS

2″ All Terrain Suspension Kit Suited For 2019+ Subaru Forester SK

Oh, the places you’ll go.

The new All Terrain Suspension (ATS) suited for the Subaru Forester is a complete suspension system for greater handling and control without compromising safety and comfort. Engineered with extended travel twin-tube gas struts, derived from our military-grade suspension, ATS provides enhanced durability and reliability in both on- and off-road environments. And with a two-inch lift, larger tires can be fitted for enhanced stability in inclement weather or on challenging roads. Ground clearance increases to an impressive 10.7 inches, so you can adventure further wherever the road takes you.

The capability to go further with the confidence you need to get back.

«Safety, comfort and performance—it’s a well-rounded package that is really quite impressive.»

Nate Tennis
Rally Driver and Lead Instructor
DirtFish Rally School

Vehicle Fitment

Make	Model	Year
Subaru	Forester	2019
Subaru	Forester	2020
Subaru	Forester	2021

Specifications

• Estimated Lift: 2″
• Estimated Ground Clearance: 10.7″

This Kit Includes:

• Front and Rear Ironman 4×4 ATS coilovers (pre-built struts and springs for front and rear)
• All mounting hardware for installation included
• Part Number: SUB007BKG
• Coil-over suspension provides approximately 2-inches of front and rear lift
• Extended travel twin-tube struts improve control and comfort
• Performance coils support additional accessory weight
• Low nitrogen charge for a smoother response
• Vehicle specific valving

**Note** May not be compatible with trailer hitches so double check your clearances ahead of install

Front Strut Extended	605mm
Front Strut Compressed	380mm
Rear Strut Extended	536mm
Rear Strut Compressed	341mm
Spring Rate Front	180(lbf/in)
Spring Rate Rear	215(lbf/in)

Installation

• Bolt-on system (no cutting or welding necessary)
• May not be compatible with trailer hitches so double check your clearances ahead of install

View Instruction Sheet

Installation Video:
